Model | A-120-LQ | A-160-LQ | A-180-LQ | A-200-LQ |
Medium width | 80cm-130cm | 120cm-170cm | 140cm-190cm | 140cm-210cm |
Max cutting width | 110cm | 150cm | 170cm | 190cm |
Max printe width | 120cm | 160cm | 180cm | 200cm |
Machine side | L192*W50*H103 | L232*W69*H103 | L252*W69*H103 | L272*W69*H103 |
Packing size | L207*W55*H55 | L247*W55*H55 | L267*W55*H55 | L287*W55*H55 |
Paper feeding and colltet mode | Back side feeding | The default is single paper feed, with optional dual paper feed system and front-mounted paper collection. |
Paper type | Applicable to CAD drawing paper such as roller fype marking paper, kraft paper, new paper ( 40-250g/m2) |
Cutter material | Applicable to CAD drawing paper such as roller type marking paper, kratt paper, new paper |
Serial interface | TCP net work interface TCP), support single ine 1-100 mefers nehwork cable, suppor direct connection computer or router, mutiple computers control printing |
Printe speed | 65-85 suqare meter /hour |
Max cut printe speed | 1200mm/sec |
Equipment panel | Touch button, Chinese and English double board, simple and durable |
Environmental Science | temperature 1-35 °C humidity rh15-85% (no condensate) |
Domain | Pattem cutting of clothing, luggage, interior decoration, toys and other industries |
Voltage / capacity | AC 220V / 50-60Hz (AC110V can be customized), UPS power should not be less than 600W |
Technical support | Provide telephone, network online and other means of technology on weekdays |
Control management software | Running platfom Windows XP //NT/2000 winlo.1The ouput printing center can control the equipment operation in rea ime.2 Support manual/ automaticprinting. 3Support the seting of equipment operation parameters. 4Ink soving mode of nozle printing s optional.5 Real time display of output printing status. (6 Click and print any segment, and automatically paginate the super width. |
